Quick Details
| Model Number: | SM-80A75B15C-En31N | Type: | Servo Motor |
| Frequency: | 50/60HZ | Phase: | Three-phase |
| Certification: | CE, ECO | Protect Feature: | Totally Enclosed |
| AC Voltage: | 220V | Efficiency: | IE 3 |
| Rated Power: | 0.75 kW | Rated Torque: | 4.8N,m |
| Rated Speed: | 1500rpm | Rated Voltage: | single Phase 220V |
| Certificated: | CE /ISO 9001/2008 | Rpm: | 3000 |
Supply Ability: 300 Set/Sets per Year
Synmot servo motors are permanent magnet synchronous motors,the main features including :ultra energy-saving .high response and accuracy .low noise and low temperature rise.the rotor is made of high-performance rare-earth permanent magnet material .works reliably and tomaintain less.With low rotary inertia .it is easy to improve the rapidity of system .small volume.high speed and high torque.using the high-resilution encoder (17-bit .33-bit) to improve the position control accuracy.it control the current according to D-P principal axis transformation .which increase the torque control accuracy from 5% to 2% .Synmot servo motor have been widely used in injection molding machienry .textile machinery.CNC machinery etc.
